Product features
Material: Brass,chromium plated
Type:JIS Standard
Entry Thread:PF
Approvals:CE,REACH
Application: For use all types of unarmoured cables.
Material: Brass,chromium plated
Type:JIS Standard
Entry Thread:PF
Approvals:CE,REACH
Application: For use all types of unarmoured cables.
Product features
Material: Brass,chromium plated
Type:JIS Standard
Entry Thread:PF
Approvals:CE,REACH
Application: For use all types of unarmoured cables.
JIs standard type
| Code | Gland size | Thread AG | Packing type | cable range(mm) | Thread length GL (mm) | Mounting hole diameter(mm) |
| JX-JIS10A JX-JIS10B |
JIS-10 | 3/8″ | A B |
6-7 7-8 |
11 | 18 |
| JX-JIS15A JX-JIS15B JX-JIS15C |
JIS-15 | 1/2″ | A B C |
8-9 9-10 9-11 |
11 | 22 |
| JX-JIS20A JX-JIS20B JX-JIS20C |
JIS-20 | 3/4″ | A B C |
11-12 12-13 12-15 |
11 | 27 |
| JX-JIS25A JX-JIS25B JX-JIS25C |
JIS-25 | 1″ | A B C |
15-16 16-18 16-20 |
11 | 34 |
| JX-JIS30A JX-JIS30B JX-JIS30C |
JIS-30 | 1-1/4″ | A B C |
20-22 22-24 22-26 |
12 | 43 |
| JX-JIS35A JX-JIS35B JX-JIS35C JX-JIS40A JX-JIS40B JX-JILS40C |
JIS-35 IS-40 |
1-1/2″ | A B C A B C |
26-28 28-30 26-30 30-32 32-34 30-34 |
12 | 49 |
| JX-JIS45A JX-JIS45B JX-JIS45C JX-JIS50A JX-JIS50B JX-JIS50C |
JIS-45 JIS-50 |
2″ | A B C A B C |
34-36 36-38 36-40 40-42 42-44 40-44 |
12 | 61 |
| JX-JIS55A JX-JIS55B JX-JIS55C JX-JIS60A JX-JIS60B JX-JIS60C |
JIS-55 JIS-60 |
2-1/2″ | A B C A B C |
44-46 46-48 46-50 50-52 52-54 52-56 |
12 | 76 |
| JX-JIS65A JX-JIS65B JX-JIS70A JX-JIS70B JX-JIS75A JX-JIS75B |
JIS-65 JIS-70 JIS-75 |
3″ | A B A B A B |
56-58 58-60 60-62 62-64 64-66 66-70 |
14 | 89 |
