Product Features
Materia: nickel-plated brass
Clamping insert: Nylon PA
Seal: nitrile rubber(NBR)
Protection class: lP68
Ambient temperature: -40C to 100℃, short time to 120°c
Materia: nickel-plated brass
Clamping insert: Nylon PA
Seal: nitrile rubber(NBR)
Protection class: lP68
Ambient temperature: -40C to 100℃, short time to 120°c
Product Features
Materia: nickel-plated brass
Clamping insert: Nylon PA
Seal: nitrile rubber(NBR)
Protection class: lP68
Ambient temperature: -40C to 100℃, short time to 120°c
| Thread | Cable Range (mm) |
Thread Length GL(mm) |
Thread O.D (mm) |
Spanner Size (mm) |
AG(mm) |
| JX-M12-BR | 3-6.5 | 7 | 11.9 | 17 | 12 |
| JX-M14-BR | 4-8 | 7 | 13.9 | 19 | 14 |
| JX-M16-BR | 4-8 | 7 | 15.9 | 21 | 16 |
| JX-M18-BR | 5-10 | 8 | 17.9 | 22 | 18 |
| JX-M20-BR | 6-12 | 8 | 19.9 | 24 | 20 |
| JX-M22-BR | 10-14 | 8 | 21.9 | 27 | 22 |
| JX-M25-BR | 10-16 | 9 | 24.9 | 27 | 25 |
| JX-M27-BR | 13-18 | 9 | 26.9 | 30 | 27 |
| JX-M28-BR | 13-18 | 9 | 27.9 | 30 | 28 |
| JX-M30-BR | 13-18 | 10 | 29.9 | 36 | 30 |
| JX-M32-BR | 15-22 | 10 | 31.9 | 38 | 32 |
| JX-M37-BR | 18-25 | 12 | 36.9 | 42 | 37 |
| JX-M40-BR | 22-30 | 12 | 39.9 | 46 | 40 |
